NKW125Q Fully Automatic Horizontal Hydraulic Baler
The NKW125Q is a fully automatic horizontal hydraulic baler engineered for high-volume material compaction in industries such as food, pharmaceuticals, packaging, chemicals, electronics, metals, and waste treatment. With a 125-ton main cylinder force and a feed opening of 2000x1100 mm, it processes up to 12 tons per hour, producing dense bales of 500-600 kg/m³. Designed for continuous PLC-controlled operation, it ensures reliable performance in demanding environments.
Key Selling Points
- High Compression Force: 125-ton main cylinder force produces dense, stackable bales, reducing storage and transport costs.
- Large Feed Opening: 2000x1100 mm opening accepts bulky materials, improving operational efficiency.
- Fully Automatic Operation: PLC-controlled cycle enables continuous operation, minimizing manual intervention.
- Robust Construction: Carbon steel mainframe ensures durability and long service life.
- Integrated Conveyor: 2000x12000 mm conveyor with 7.5 kW motor streamlines material feeding.
Technical Specifications
| Model | NKW125Q |
| Bale Size (W×H×L) | 1100×1100×1600 mm |
| Material Density | 500–600 kg/m³ |
| Feed Opening Size | 2000×1100 mm |
| Main Motor Power | 37.5 kW + 11 kW |
| Conveyor Motor Power | 7.5 kW |
| Capacity | 10–12 tons/hour |
| Main Cylinder Force | 125 tons |
| Mainframe Weight | 22 tons |
| Mainframe Size (L×W×H) | 11×2.3×2.9 m |
| Conveyor Size | 2000×12000 mm |
| Working Pressure | 21 MPa |
Models and Options
This model is available in fully automatic and semi-automatic configurations to suit different production requirements.
Materials and Structure
The mainframe is constructed from carbon steel, providing high strength and resistance to wear. The hydraulic system is designed for low noise and energy efficiency, meeting the demands of continuous industrial operation.
Applications
Suitable for compacting and packaging materials in food processing, pharmaceuticals, packaging, chemicals, electronics, metals, waste treatment, and recycling industries.
Customization
Customization options include conveyor length, PLC programming, and auxiliary equipment such as wire tying or bagging units. Contact us for tailored solutions.
FAQ
What is the bale density?
The bale density ranges from 500 to 600 kg/m³, ensuring compact and manageable bales.
What is the capacity of this baler?
The capacity is 10-12 tons per hour, depending on material type and feeding method.
Does it come with a conveyor?
Yes, the standard configuration includes a 2000×12000 mm conveyor with a 7.5 kW motor.
What is the working pressure?
The system operates at 21 MPa, ensuring high compression force.
Can it handle high-temperature materials?
The baler is designed for general industrial use, but specific high-temperature applications should be discussed with our engineers.
What are the electrical requirements?
The main motor power is 37.5 kW plus 11 kW, and the conveyor motor is 7.5 kW. Standard three-phase power supply is required.
Is the machine CE certified?
Yes, our machinery complies with CE standards, including EN ISO 12100:2010 and EN 60204-1:2018.
What is the delivery method?
Delivery is available via FOB or CIF. Pre-shipment testing is performed to ensure quality.
